Interactive Flat Panels: The Future of Digital Interaction
Transform your workspace or classroom with SaGaVision™, an all-in-one multi-function smart panel designed to help you "Interact Smartly". Available in a full spectrum of sizes from 55" to 110", these panels are engineered for high-performance delivery in both Smart Classrooms and professional Video Conferencing environments.
More Than Just a Display: The SaGa Experience
The SaGaVision IFP is a comprehensive ecosystem powered by a Dual OS (Android 14.0 & Windows), giving users the reliability of redundancy and a vast choice of applications.
Endless Canvas
Write without limits by dragging the canvas in any direction to accommodate all your ideas.
Video Annotation
Annotate directly over live video and extract motionless images for further study or presentation.
Discipline-Specific Tools
Enhance practical learning with shape simplification, equation solving, and virtual lab experiments for Physics, Math, and Chemistry
Dual Pen Functionality
Write in multiple colors simultaneously to differentiate notes and increase engagement.
Wireless File Transfer
Seamlessly move documents to the panel simply by scanning a QR code.
Google EDLA Certified
Enjoy a secure and optimized experience with official Google Enterprise Device Licensing Agreement certification.
Specifications
| Category | Parameter | Specifications |
|---|---|---|
| Display | Resolution | 4K UHD (3840 x 2160) |
| Brightness | 350-400 cd/m2 | |
| Contrast Ratio | 5000:1 | |
| Viewing Angle | H:178°, V:178° | |
| Backlight Type | D-LED (Life >50,000 Hours) | |
| Glass | 8mm Physical Tempered, Grade 7 Explosion-Proof, Anti-Glare | |
| System | Operating System | Android 14.0 (Dual OS Support for Windows/macOS) |
| CPU | Arm Cortex-A55*8, Octa-Core | |
| GPU | Mali-G52 MP | |
| RAM / ROM | 8GB DDR4 / 128GB eMMC | |
| Touch | Technology | High Precision Infrared Touch |
| Touch Points | 20 Points (Android) / 40 Points (Windows) | |
| Response Time | <4ms | |
| Precision | ±1mm | |
| Input | Finger, Touch Pen, or 3mm Non-Transparent Object | |
| Connectivity | Front Ports | 3x USB 2.0, 1x HDMI, 1x Touch USB-B, 1x Type-C |
| Rear Ports | 2x RJ45/LAN, 1x Touch USB, 2x HDMI, 2x USB 3.0, 1x VGA, 1x PC Audio, 1x Type-C, 1x Display Port, 1x Optical Out, 1x HDMI Out | |
| Audio/Power | Audio | Built-in Stereo (25W x 2) |
| Power | AC 100-240V; Consumption: 220W (Typical), <0.5W (Standby) |
Optional Accessories for a Complete Setup
IFP Trolley for mobile flexibility.
Safety Slider Boards for integrated traditional and digital teaching.
Web & PTZ Cameras for high-definition video conferencing and lecture recording
Interactive Video Library for recorded lectures and YouTube videos
OPS Module for enhanced dedicated computing power and WINDOWS OS
